Temperature Scanners data loggers

TEMPERATURE SCANNERS-DATA LOGGERS

The ASHE Series MAX range of microcontroller based multi-channel Temperature Scanners are compact, rugged and reliable instruments designed for accurate measurement and control applications.

The Scanners are fully configurable instruments with options of 2/4/8/16 channel inputs, which can accept Thermocouple (J,K,R,S,T,E) sensors and RTD Pt-100 (three-wire) sensors. Upto four Relay outputs are offered as assignable control outputs, each of which can switch a load of up to 10 Ampere rating. Separate displays are provided for channel number and it’s corresponding temperature. The instrument operates on 85 to 270 V, 50/60 Hz Universal AC power supply and is offered in % DIN standard panel-mount execution. Options include settings for Channel Skip and Scan Time, Analog Retransmission signals, weather-proof/flame-proof/panel mount options, etc.

All ASHE instruments carry a lifetime warranty against defects in components and workmanship.
