flexco

CLIPPER® WIRE HOOK FASTENING SYSTEM

The Clipper® Wire Hook Fastening System is designed with a variety of different wire diameters, leg and point lengths, metals, strip lengths, and styles to meet your individual application needs.

WHY WIRE HOOKS?

• Mechanical fastener rating up to 200 PIW (35 kN/m)

• Belts up to 25/64” (10 mm) thick

• Minimum pulley diameter from 15/16” to 7” (24 mm to 175 mm)

• Available in two hook styles:

• Unibar® Fasteners – welded to a common bar to enhance installation safety and ease meshing of belt ends

• Carded Fasteners – individual hooks secured on carding paper for safe handling

• Low-profile design is conveyor component compatible

• Quiet operation when contacting pulley and other conveyor components

• Double-staggered grip pattern offer exceptional holding power, does not degrade integrity of belt

• Quick, economical installation

INSTALLATION METHOD

Maintenance Lacers with Roller Lacing Technology™ – Lightweight, portable installation tools which gently and precisely roll the hooks into the belt for a low-profile splice

Production Lacers – For high-volume production lacing

Specialty Lacers – Featuring continuous lacing
