Medical CNC Machining
Precision Medical Devices, Tools, and Components Machined in a Controlled Environment
BDE Manufacturing has established a reputation in the precision manufacturing of quality medical devices, tools, and components. We are aware of the stringent compliance standards required in the medical industry. Our adherence to close tolerances, and in-depth understanding of the client and end-user requirements have helped us survive all these years.
Medical Machining Capabilities
Our following machining capabilities have helped us gain prominence in the highly competitive medical industry.
Electric Discharge Machining (EDM): This process helps achieve a high level of accuracy with +/- 0.0001” typical tolerances. We can provide tapered cuts up to 25 degrees depending on the height of the work piece. Many of our medical industry clients have approached us for wire EDM services. In this method, the material to be cut is submerged in a dielectric cutting fluid, usually deionized water. A thin single-strand wire electrode continuously travels through the workpiece while an electric current is run through the wire, creating an electrical spark of intense heat (8000-12000°C). The electrical spark cuts the material by removing the metal content through melting and vaporization. The CNC controlled upper and lower guides are independently programmable from each other allowing for 2 separate profiles to be cut on the same work piece. At the same time, the dielectric cutting fluid cools the material and flushes away particles that have been cut from it.
CNC Turning Services: In this process, a cutting tool is used to cut a material, which is spinning at high RPM. This technique is appropriate for materials that require high rotational symmetry.
