Heavy Duty Accumulating Roller Chain Conveyor

Heavy Duty Accumulating Roller Chain Conveyor

Product Information

 Low back pressure accumulating roller chain conveyor, SRF-P 2012, is designed for the construction of heavy-duty pallet handling systems or for conveying large or bulky products. The free running rollers, within the chain, ensure quiet operation and a smooth accumulating surface.

Features:

• Frme: 135 mm deep profile, 60 mm wide
• Pulley: 3/4" pitch
• Width: Each lane is 60 mm wide, outside frame width is nearly unlimited, single or multiple lanes
• Length: 500 mm to 20,000 mm
• Load: Up to 800 lbs. per pallet, 3,500 lbs. per drive
• Speed: Up to 200 fpm (speeds up to 80 fpm are preferred for VersaMove)
• Costant or Variable speed options
• Voltage: All standard US, Mexico and Canadian voltages
• Chain: 3/4" pitch accumulating roller chain
• Plastic or steel rollers
• In-line or staggered rollers
• Accessories: Compatible with all mk side rails and support
